Honeywell · Personal shopper

Honeywell CS32

The CS32 is designed for self-service shopping with independent scanning and payment, reducing wait times and operational costs through its hardware, user-friendly design and adaptable software ecosystem to enable retail digital transformation.

Operating systemAndroid Android 14, upgradable to Android 16 and Android 18, subject to technical feasibility confirmed by…
Display15.2 cm (6.0 in)
ScanningN6700; imager; Honeywell N6700 (1D/2D barcode symbologies)
Battery6700mAh; Store-swappable 6700mAh Store-swappable
SealingIP30
DropMultiple 1.2m (4ft) drops to concrete over temp (-10° C to 50° C/14° F to 122° F) per MIL-STD 810H

Datasheet at Honeywell Product page at Honeywell

Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps

Specifications

Connectivity: Wi-Fi Wi-Fi & Cellular
Environment: Standard
Application: Retail
Dimensions: 275mm x 78mm x 13.9mm (10.8 in x 3.0 in x 0.55 in)
Decode Capability: Honeywell N6700 (1D/2D barcode symbologies)
Computer Wireless Communication: WiFi 6E, V5.3 Bluetooth, NFC
Bluetooth Specifications: V5.3 Bluetooth with BLE
WLAN Specifications: Additional WLAN Features: 802.11 d/e/h/i/k/r/u/v/w/mc WLAN (Wi-Fi Alliance certified): IEEE 802.11 a/b/g/n/ac/ax (2.4GHz, 5GHz, 6GHz3, 2X2 MU-MIMO, DBS supported, IPv4, IPv6
Operating System Type: Android
Operating system: Android 14, upgradable to Android 16 and Android 18, subject to technical feasibility confirmed by Qualcomm
Platform: Mobility Edge™ Platform
RAM / storage options: 8 GB RAM/128 GB Flash
Keyboard / keys: Full Touchscreen
Display resolution: Full High-Definition (1080 x 2160)
Scan Engine Range: Standard range / mid range
Scan Engine Model: N6700
Scan Engine Type: imager
Scan range / decode distances: Mid Range (0-5m) Standard Range (0-1m)
Display size: 15.2 cm (6.0 in)
Scan Range: Mid Range (0-5m) Standard Range (0-1m)
Processor: Qualcomm 4490 octa-core
Battery / runtime: 6700mAh
Battery Types: Li-Ion, 3.635V
Battery / runtime: Store-swappable
Storage temperature: -30° to 70°C (-22°F to 158°F)
Operating temperature: -20° to 50°C (-4°F to 122°F)
Humidity: 5% to 95% (non-condensing)
Tumble specification: 1000, 0.5m (1.6 ft) tumbles
Drop specification: Multiple 1.2m (4ft) drops to concrete over temp (-10° C to 50° C/14° F to 122° F) per MIL-STD 810H
Protection Ratings: IP30
Warranty Duration: One-year factory warranty
Industry: Retail
Connectivity: Wi-Fi|Wi-Fi & Cellular
WLAN Specifications: Additional WLAN Features: 802.11 d/e/h/i/k/r/u/v/w/mc|WLAN (Wi-Fi Alliance certified): IEEE 802.11 a/b/g/n/ac/ax (2.4GHz, 5GHz, 6GHz3, 2X2 MU-MIMO, DBS supported, IPv4, IPv6
Scan range / decode distances: Mid Range (0-5m)|Standard Range (0-1m)
Scan Range: Mid Range (0-5m)|Standard Range (0-1m)
X: BRV900~51400955-100
Display: Corning® Gorilla® Glass 5,15.2 cm (6.0 in)
Operating temperature: (-4°F to 122°F)
Storage temperature: (-22°F to 158°F)

Manufacturer lists options and regional variants. Confirm selected SKU, delivered OS and scan engine.

Lifecycle

Sales status: Current catalogue
Status basis: Listed in official model catalogue; regional orderability requires confirmation.
