Honeywell · Handheld computer

Honeywell EDA52

Honeywell ScanPal™ EDA52 is an enterprise-class mobile computer that provides reliable and secure connectivity between frontline workers and backend systems. It's designed for retail use, logistics, manufacture, healthcare and public service.

Operating systemAndroid Android 11, and upgradeable to Android 13 (Android 13 is pending for the confirmation from Qualcomm…
DisplayGorilla Glass 5, 5.5-inch
ScanningHoneywell S0703 Slim Imager (1D/2D barcode symbologies)
Battery3.8 V, 4,500 mAh, removable; Li-Ion 3.8 V, 4,500 mAh, removable Li-Ion
DropMultiple 1.3m (4.3ft) per MIL-STD 810G drops to concrete at room temperature|Multiple 1.5m (5ft) per MIL-STD…

Datasheet at Honeywell Product page at Honeywell

Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps

Specifications

Cameras: Front: 5-megapixed color camera Rear: 13 - megapixel color camera
Camera Position: Front and Rear
Connectivity: Wi-Fi Wi-Fi & Cellular
Environment: Healthcare Standard
Application: Retail, transportation & logistics, manufacturing, healthcare, and public service
Durability: Electrostatic Discharge (ESD): ±8 kV direct; ±15 kV air Environmental Sealing: IP67
Dimensions: 159mm x 75 mm x 14.4 mm (6.26 in x 2.95 in x 0.57 in)
Decode Capability: Honeywell S0703 Slim Imager (1D/2D barcode symbologies)
Bluetooth Specifications: Bluetooth Class 5.1
WWAN Specifications: FDD-LTE: Bands 1, 2, 3, 4, 5, 7, 8, 9, 12,13,17,19,20,25,26,28,30,66 GSM/EDGE: Bands 2, 3, 5, 8 TDD-LTE: Bands 38, 39, 40, 41 UMTS/HSPA+: Bands 1, 2, 4, 5, 6,8, 9, 19
WLAN Specifications: Additional WLAN Features: 802.11 d/e/h/i/k/ r/u/w Security: OPEN, WEP, WPA/WPA2 (Personal and Enterprise WPA2), WPA3 (OWE, SAE, Enterprise) WLAN (Wi-Fi Alliance certified): 802.11 a/b/g/n/ac WLAN Supported EAP: TLS, PEAP, TTLS, PWD, LEAP
GPS Specifications: GPS (WWAN only) Supported Protocols: Simultaneous receiver support for GPS, GLONASS, and BeiDou
Operating system: Android 11, and upgradeable to Android 13 (Android 13 is pending for the confirmation from Qualcomm & Google)
RAM / storage options: Storage Expansion: MicroSD (up to 128 GB)
Display resolution: 1440 x 720 High Definition
Scan Engine Model: Honeywell S0703 Slim Imager (1D/2D barcode symbologies)
Scan range / decode distances: Standard Range (0-1m)
Display size: Gorilla Glass 5, 5.5-inch
Processor: Qualcomm Snapdragon SM6115, Quad high-performance Kryo cores 2.0 GHz +Quad low-power Kryo cores 1.8 GHz
Keyboard / keys: Full Touchscreen
Battery / runtime: 3.8 V, 4,500 mAh, removable
Battery Types: Honeywell
Battery / runtime: Li-Ion
Operating temperature: -20°C to +50°C (-4°F to +122°F)
Humidity: 5% to 90% (non-condensing)
Tumble specification: 550 times at 0.5 m (1.64 ft)
Drop specification: Multiple 1.3m (4.3ft) per MIL-STD 810G drops to concrete at room temperature Multiple 1.5m (5ft) per MIL-STD 810G drops with rubber boot concrete at room temperature
Industry: Retail
Cameras: Front: 5-megapixed color camera|Rear: 13 - megapixel color camera
Connectivity: Wi-Fi|Wi-Fi & Cellular
Environment: Healthcare|Standard
Durability: Electrostatic Discharge (ESD): ±8 kV direct; ±15 kV air|Environmental Sealing: IP67
WWAN Specifications: FDD-LTE: Bands 1, 2, 3, 4, 5, 7, 8, 9, 12,13,17,19,20,25,26,28,30,66|GSM/EDGE: Bands 2, 3, 5, 8|TDD-LTE: Bands 38, 39, 40, 41|UMTS/HSPA+: Bands 1, 2, 4, 5, 6,8, 9, 19
WLAN Specifications: Additional WLAN Features: 802.11 d/e/h/i/k/ r/u/w|Security: OPEN, WEP, WPA/WPA2 (Personal and Enterprise WPA2), WPA3 (OWE, SAE, Enterprise)|WLAN (Wi-Fi Alliance certified): 802.11 a/b/g/n/ac|WLAN Supported EAP: TLS, PEAP, TTLS, PWD, LEAP
Drop specification: Multiple 1.3m (4.3ft) per MIL-STD 810G drops to concrete at room temperature|Multiple 1.5m (5ft) per MIL-STD 810G drops with rubber boot concrete at room temperature
X: BRV900~51400955-100
Dimensions: 159mm x 75 mm x 14.4 mm
Operating temperature: -20°C to +50°C (-4°F to +122°F)
Storage temperature: -30°C to +70°C (-22°F to 158°F)
Dimensions: 159mm x 75 mm x 14.4 mm
Operating temperature: -20°C to +50°C (-4°F to +122°F)
Storage temperature: -30°C to +70°C (-22°F to 158°F)

Manufacturer lists options and regional variants. Confirm selected SKU, delivered OS and scan engine.

Lifecycle

Sales status: Current catalogue
Status basis: Listed in official model catalogue; regional orderability requires confirmation.
